ROLLER COMPACTOR OR ROLL COMPACTOR
PRINCIPLE OF ROLLER COMPACTION
Riddhi Roller Compaction is a dry granulation method. The basic concept is to force fine powder into solid compact or sheet. Some of the factors controlling the compaction process are roll surface, diameter, peripheral speed, separating force or pressure capabilities, feed screw and being processed. The addition of binders to the material being processed. The addition of binders to the material being processed greatly reduces the production of fines.
AN OUTSTADING FEATURE
Roller Compactor is totally G.M.P., compact design-plain as well as water jacketed for products which are extremely heat sensitive. Various types of rolls can be offered to suit your specific application so as to achieve maximum bulk density of output eg. (A) Plain (b) corrugated (c) Briquetted & (d) knurled.
Roller Compactors Specially designed feeding system consisting of hopper pre-densifier and a variable speed drive unit. Safety clutch is provided to prevent any accident.
Roller Compactors Feeding unit can be hydraulically lifted by hand operated hydraulic pump for easy cleaning and built-in panel and indicators are provided, on-off, feed screw, main switch, forward/reverse switches. RPM indicators for roll and feed screw, emergency stop, digital RPM indicator etc.
Roller Compactor Specially designed scraper is provided to prevent powder sticking on the rolls.
Roller Compactor design of the equipment is such that minimum lubrication is required in daily maintenance.
Roller Compactor’s main roll drive is designed with twin shaft gear box coupled with safety clutch to protect roll drive unit thereby perfectly synchronizing the roll with a steady torque.
The side seal is forced against the roll side, so that the percentage of uncompacted powder that leaks by is kept extremely low.
To prevent a possible accident the compacting roll is designed to rotate backward when cleaning.
N. B.: Can offer free trials at our factory before purchase, decision is taken.
RIDDHI ROLLER COMPACTOR GMP MODEL
TECHNICAL SPECIFICATIONS :
| MODELS |
RDRC-200/50 |
RDRC-200/75 |
| Max. Output (kgs/hr) |
20 to 60 |
30 to 100 |
| Roll Speed |
6 to25 RPM |
6 to25 RPM |
| Feed Screw Speed |
10 to 60 RPM |
10 to 60 RPM |
| Roll Drive Motor |
5 HP. 3. A.C. |
5 HP. 3 . A.C. |
| Feed Screw Drive Motor |
1 HP. 3. A.C. |
1 HP. 3 . A.C. |
RIDDHI ROLLER COMPACTOR GMP MODEL
TECHNICAL SPECIFICATIONS :
| MODELS |
RDRC-200/100 |
RDRC-200/150 |
| Max. Output (kgs/hr) |
100 to 250 |
100 to 350 |
| Roll Speed |
6 to 22 RPM |
6 to 22 RPM |
| Feed Screw Speed |
16 to 50 RPM |
6 to 50 RPM |
| Roll Drive Motor |
7.5 HP. 3. A.C |
10 HP. 3. A.C. |
| Feed Screw Drive Motor |
3 HP. 3. A.C |
3 HP. 3. A.C. |
RIDDHI MINI ROLLER COMPACTOR LAB MODEL
TECHNICAL SPECIFICATIONS :
| MODELS |
RDMRC-2/5 |
| Max. Output (kgs/hr) |
2 to 5 |
| Roll Speed |
6 to 29 RPM |
| Feed Screw Speed |
5 to 86 RPM |
| Roll Drive Motor |
1.5 HP. 3. A.C. |
| Feed Screw Drive Motor |
1 HP. 3. A.C. |
